JLG X1000AJ

New JLG Compact Crawler Boom for Sale

New JLG X1000AJ Compact Crawler Boom for Sale

Our line of electric and hybrid boom lifts are environmentally friendly, energy efficient and help keep productivity high. From job start to completion, JLG has an electric boom lift to meet your needs and keep your job green.

  • Lightweight, compact non-marking rubber track-mounted booms
  • Optional Lithium-ion battery for cleaner, greener operation
  • Self-leveling, non-marking outriggers for use on uneven surfaces
  • Choose from five models with working heights up to 75 ft



Compact Crawler lifts feature low weight and rubber tracks that allow you to go more places around the job site. They are environmentally friendly with standard AC power, gas or an optional lithium-ion electrical system that doesn’t produce emissions. These lifts climb slopes with ease thanks to their tracked wheel carriage, and their narrow chassis allows for access through gates, yards, standard doorways and public buildings. This makes a Compact Crawler lift ideal for various jobs both indoors and out.
Dimensions
Length 21’3” (stowed w/basket)
19’3” (stowed wo/basket)
Width 3’11”
Height 6’6” (stowed)
56’5” (Up and Over Height)
Weight 16,790 lbs.
Platform Capacity: 500 lbs.
Engine/Drivetrain
Engine Make Kubota
Engine Type D902 21.6 HP
Horsepower 21.6 HP
Fuel Tank Capacity 6.6 Gallons
Track Length 6’10”
Ground Pressure 58 PSI (Bearing Pressure—Outriggers)
11.3 PSI (Max. Bearing Track Pressure)
Track Speeds 11 mph
Hydraulic
Hydraulic Capacity 21 gallons
Operational
Approach Angle Front: 18° (33%)
Rear: 16° (29%)
Leveling Capability 16°
Pad Diameter 15.7”
Performance
Tracks Standard Non-Marking Tracks
Jib 180° (+85/-95 Degrees)
Outriggers Footprint from Outer Edge
Total Stabilization Area: 18’2” x 16’5”
Reduced Stabilization Area: 22’ x 12’2”
Gradeability 28%
Platform Height 100’
Platform Size 63” x 28”
Horizontal Reach 54’2”
Swing 360° Non-Continuous
Working Height 106’
  • Enhanced Reach – Class-leading 56-ft up and over work envelope and 54-ft horizontal outreach
  • Improved Stability – One-touch, self-leveling, multi-position outriggers
  • More Power Options – 76V advanced technology 2.0 lithium-ion battery for quiet indoor operation or Kubota D902 diesel engine power for outdoor jobs
  • Compact Dimensions – Best-in-class compact stowed length and the ability to fit through standard double doors
  • Easy Transport – Fork lift pockets and heavy-duty lifting hooks
  • ANSI Compliant – Meets most up-to-date A92.20 ANSI standards
  • Multi-Position Outriggers
  • Below Grade Capability
  • Color Remote and Ground Panel Provides Onboard Diagnostics
  • One-touch Outrigger Leveling
  • 110V-AC receptacle in Platform
  • Standard Air/Water Line
  • Patented Quick Disconnect Platform
  • Large Teflon®  Outrigger Pads
  • Fork Pockets and Lifting Hooks
  • Caster Platform Wheels
  • Fully Synthetic Biodegradable Hydraulic Fluid
  • 360° Non-Continuous Swing
  • 180° Platform Rotator
  • QuikStik®
  • SkyGuard®
  • Optional Flashing Amber Beacon
