Vogele Super 2003-3i

Vogele Super 2003-3i

New Vogele Super 2003-3i Paver for Sale

With the SUPER 2003-3i VÖGELE has now developed an entirely new paver specially for the North American market. The wheeled SUPER 2003-3i is designed primarily for use in highway construction and large-scale commercial applications, which are all about power and productivity. With a powerful, 6-cylinder Cummins engine rated at 250 hp (186 kW) and high-output hydraulic drives, it is fully equipped for these jobs.
Dimensions
Length VF 600: 21'4"
VR 600: 22'6"
AB 600: 21'9"
Width 11'3"
Height 12'8"
Weight VF 600: 46,848 lbs
VR 600: 47,730 lbs
AB 600: 47,510 lbs
Inside Turning Radius 18ft. 4in. (with “Pivot Steer”)
Engine
Fuel Tank Capacity 85 gal
Engine/Drivetrain
Engine Make Cummins
Engine Model QSB 6.7 C-250
Cylinders 6
Horsepower Nominal: 250 hp / 2,000 rpm
ECO MOde: 235 hp / 1,700 rpm
Cooling Liquid-cooled
Fuel Type Diesel
Roller Type Push-Rollers: oscillating, displaceable forwards by 3 in. and 6 in.
Traction Drive Separate hydraulic drive provided for each wheel
Standard: 2 rear wheels powered
Options:
-2 rear wheels and 2 front wheels powered (6x4)
-2 rear wheels and 4 front wheels powered (6x6)
Operational
Dump Height 24 in. (bottom of material hopper)
Paving Speed Up to 250 fpm
Travel Speed - Forward Up to 12 mph
Hopper Width 11 ft.
Paving
Paving Width VF 600: 25'
VR 600: 24'
AB 600: 24'
Screed Width VF 600: 10' up to 19.52'
VR 600: 10' up to 19.68'
AB 600: 9'1" up to 6'
Hopper
Hopper Capacity 33,070 lbs
Conveyor 2, with replaceable feeder bars, conveyor movement reversible for a short time
Drive: Separate hydraulic drive provided for each conveyor
Speed: Up to 197 fpm infinitely variable
  • Type: Wheeled Paver
  • Nominal output: 250 HP
  • Basic Width: 9’10”
  • Paving width, max.: 25’5”
  • Maximum laydown rate: 1,540 US t/hr
  • Transport Width: 10’



  • 10-foot wheeled Highway Class paver with a large range of applications and paving widths up to 25 ft. 6 in. (7.75 m)
  • Powerful Cummins engine complying with US EPA standard Tier 4f
  • Innovative and reliable drive concept for excellent traction behavior
  • Perfect paving quality due to perfect material management
  • ErgoPlus 3 with a number of additional ergonomic and functional advantages
  • Daily maintenance-free paver with auto-lubrication and more
  • The right screed for every application: the paver can be combined with the VF 600, VR 600 or AB 600 Extending Screeds



  • Large receiving hopper holding 16.5 tons (15 tonnes)
  • Hydraulic hopper front
  • Simple, ergonomic ErgoPlus 3 operating concept
  • Working lights, LED
  • Powerful oil-cooled generator
  • VOGELE EcoPlus low-emissions package
  • Sonic sensor to control augers
  • Power Tunnel – hydraulically adjusted limiting plates for auger tunnel
  • Niveltronic Plus System for Automated Grade and Slope Control
  • WITOS Paving FleetView Telematics System
  • Ventilation System
  • Truck hitch
  • LED light balloon for use at night
  • NEMA power outlet, 120 V
  • Various sensor types are available for the Niveltronic Plus
  • VOGELE RoadScan comprehensive asphalt temperature measuring system

*Price, if shown, is Manufacturer's Suggested Retail Price (MSRP) and does not include government fees, taxes, dealer freight/preparation, dealer document preparation charges or any finance charges (if applicable). MSRP and/or final actual sales price will vary depending on options or accessories selected.

*Price, if shown, is Manufacturer's Suggested Retail Price (MSRP) and does not include government fees, taxes, dealer freight/preparation, dealer document preparation charges or any finance charges (if applicable). MSRP and/or final actual sales price will vary depending on options or accessories selected.

New Equipment Sales only available in assigned territories where Kirby-Smith Machinery, Inc. is a licensed distributor. Not all manufacturer's brands available at each location. Please contact your local Kirby-Smith branch if you have questions regarding availability.

View Brochure

Main Technical Specifications
MAKE Vogele
MODEL Super 2003-3i

Want to rent it?

Do you want to know if renting makes more economical sense?
Call us and find out today.

Vogele Super 2003-3i

print
6715 W. Reno
Oklahoma City, OK 73127 Phone: 888.861.0219
www.kirby-smith.com
CUSTOMER
DATE
PRICE
SALESPERSON

New Vogele Super 2003-3i Paver for Sale

With the SUPER 2003-3i VÖGELE has now developed an entirely new paver specially for the North American market. The wheeled SUPER 2003-3i is designed primarily for use in highway construction and large-scale commercial applications, which are all about power and productivity. With a powerful, 6-cylinder Cummins engine rated at 250 hp (186 kW) and high-output hydraulic drives, it is fully equipped for these jobs.
GENERAL INFORMATION
Manufacturer
Vogele
Model Year
Model
Super 2003-3i
Condition
NEW
Dimensions
Length
VF 600: 21'4" VR 600: 22'6" AB 600: 21'9"
Width
11'3"
Height
12'8"
Weight
VF 600: 46,848 lbs VR 600: 47,730 lbs AB 600: 47,510 lbs
Inside Turning Radius
18ft. 4in. (with “Pivot Steer”)
Engine
Fuel Tank Capacity
85 gal
Engine/Drivetrain
Engine Make
Cummins
Engine Model
QSB 6.7 C-250
Cylinders
6
Horsepower
Nominal: 250 hp / 2,000 rpm ECO MOde: 235 hp / 1,700 rpm
Cooling
Liquid-cooled
Fuel Type
Diesel
Roller Type
Push-Rollers: oscillating, displaceable forwards by 3 in. and 6 in.
Traction Drive
Separate hydraulic drive provided for each wheel Standard: 2 rear wheels powered Options: -2 rear wheels and 2 front wheels powered (6x4) -2 rear wheels and 4 front wheels powered (6x6)
Operational
Dump Height
24 in. (bottom of material hopper)
Paving Speed
Up to 250 fpm
Travel Speed - Forward
Up to 12 mph
Hopper Width
11 ft.
Paving
Paving Width
VF 600: 25' VR 600: 24' AB 600: 24'
Screed Width
VF 600: 10' up to 19.52' VR 600: 10' up to 19.68' AB 600: 9'1" up to 6'
Hopper
Hopper Capacity
33,070 lbs
Conveyor
2, with replaceable feeder bars, conveyor movement reversible for a short time Drive: Separate hydraulic drive provided for each conveyor Speed: Up to 197 fpm infinitely variable
