Multiquip RX1575

New Multiquip RX1575 Compactor for Sale

New Multiquip RX1575 Walk-Behind Roller for Sale

The MQ Rammax RX1575 articulating trench roller is designed to meet contractor expectations for performance and reliability.  Contractors will also appreciate the flexible drum options with easy to remove drum rings to adjust from 33" to 24" working widths.
Dimensions
Length 78”
Width RX1575-24”
RX157533-33”
Height 52”
Weight RX1575-3,087 lbs.
RX157533-3,197 lbs.
Inside Turning Radius RX1575-61”
RX157533-57”
Centrifugal force 16,860 lbs. (High)
8,430 lbs. (Low)
Outside Turning Radius RX1575-86"
RX157533-90"
Engine
Engine Make Yanmar
Engine Model 3TNV76
Horsepower 20 HP
Fuel Tank Capacity 74 gallons
Rated Speed 2400 RPM
Hydraulic
Hydraulic Tank Capacity 4.2 gallons
Operational
Drum Width 24/33”
Vibration Frequency 2,460 VPM
Travel Speed - Forward 145 ft/min (High)
82 ft/min (Low)
Amplitude 0.043" (High)
0.024" (Low)
Grade 40/50 (Max w/wo vibration)
Range of Operation Infrared: 65' (Max); 8' (Min)
Cable Connected: 13' (Max); 8' (Min)
  • Flexible drum options include easy to remove drum rings that adjust from 33” to 24” working widths or 33” solid drums.
  • Compaction performance and increased stability on uneven surfaces with a maintenance free oscillating
  • articulation joint.
  • Gain traction on tough material with steel padded drums and four scrapers.
  • Increased control in all terrain conditions with a wireless remote transmitter covering a wider operational area & two ideally positioned receiver eyes.
  • Charge the remote control battery with a solar panel or cable connector.
  • Total safety concept reduces job site hazards. Visual contact is required between remote transmitter and receiver eyes. Roller automatically stops within 8 ft. (2.5m) of the operator.
  • Powerful Yanmar diesl engine liquid cooled, 3 cylinder engine is EPA Tier 4 compliant. Delivers exceptional performance even in high altitude applications.
  • Able to withstand rugged work environments and steer quickly and precisely with two steering cylinders.
  • Easy access to all maintenance points with fold-up front and rear covers.
  • Shutdown safety bar
  • Removable drum Rings for RX1575

*Price, if shown, is Manufacturer's Suggested Retail Price (MSRP) and does not include government fees, taxes, dealer freight/preparation, dealer document preparation charges or any finance charges (if applicable). MSRP and/or final actual sales price will vary depending on options or accessories selected.

*Price, if shown, is Manufacturer's Suggested Retail Price (MSRP) and does not include government fees, taxes, dealer freight/preparation, dealer document preparation charges or any finance charges (if applicable). MSRP and/or final actual sales price will vary depending on options or accessories selected.

New Equipment Sales only available in assigned territories where Kirby-Smith Machinery, Inc. is a licensed distributor. Not all manufacturer's brands available at each location. Please contact your local Kirby-Smith branch if you have questions regarding availability.

View Brochure

Main Technical Specifications
MAKE Multiquip
MODEL RX1575

Want to rent it?

Do you want to know if renting makes more economical sense?
Call us and find out today.

Multiquip RX1575

print
6715 W. Reno
Oklahoma City, OK 73127 Phone: 888.861.0219
www.kirby-smith.com
CUSTOMER
DATE
PRICE
SALESPERSON

New Multiquip RX1575 Walk-Behind Roller for Sale

The MQ Rammax RX1575 articulating trench roller is designed to meet contractor expectations for performance and reliability.  Contractors will also appreciate the flexible drum options with easy to remove drum rings to adjust from 33" to 24" working widths.
GENERAL INFORMATION
Manufacturer
Multiquip
Model Year
Model
RX1575
Condition
NEW
Dimensions
Length
78”
Width
RX1575-24” RX157533-33”
Height
52”
Weight
RX1575-3,087 lbs. RX157533-3,197 lbs.
Inside Turning Radius
RX1575-61” RX157533-57”
Centrifugal force
16,860 lbs. (High) 8,430 lbs. (Low)
Outside Turning Radius
RX1575-86" RX157533-90"
Engine
Engine Make
Yanmar
Engine Model
3TNV76
Horsepower
20 HP
Fuel Tank Capacity
74 gallons
Rated Speed
2400 RPM
Hydraulic
Hydraulic Tank Capacity
4.2 gallons
Operational
Drum Width
24/33”
Vibration Frequency
2,460 VPM
Travel Speed - Forward
145 ft/min (High) 82 ft/min (Low)
Amplitude
0.043" (High) 0.024" (Low)
Grade
40/50 (Max w/wo vibration)
Range of Operation
Infrared: 65' (Max); 8' (Min) Cable Connected: 13' (Max); 8' (Min)
