Denis Cimaf DAF Front-Mounted Mulchers

New Denis Cimaf Mulcher for Sale

New Denis Cimaf DAF Front-Mounted Mulchers for Sale

The DAF is an industrial high-power forestry brushcutting-mulching system that can be installed on most compact loaders or other dedicated forestry carriers. DAF brushcutters and mulchers are designed for vegetation control work.

  • MOTOR: One or two variable displacement, axial-piston motors that minimize overheating and improve re-acceleration
  • DRIVE: Industrial cogged-belt drive system that prevents slippage and reduces effort applied to bearings compared with V-belts, for longer bearing life
  • RINGS: Protective rings that limit the size of the bites and considerably reduce risks of breakage on the knife holders
  • KNIVES: Heat-treated, bolt-on forged knives that deliver maximum resistance to impact and abrasion, and that can be sharpened right on the unit
  • EASY REPLACEMENT: A single nut and bolt holds the knife in place, making replacing worn knives easy
  • HYDRAULIC PUSHBAR OPTION: Especially useful when working in older growth as a secure way to direct where big trees will fall when cutting them down
  • REPLACEABLE LINER: With the high speeds and forces involved in industrial mulching, even the hardest steel frame is subject to wear and tear. This easy-to-replace, bolt-in wear liner extends the lifetime of the unit by protecting the frame.

Models

  • DAF-250Ex
  • DAF-225Ex
  • DAF-225E
  • DAF-180E
  • DAF-180D
  • DAF-150D
Body
Number of Blades DAF-250Ex: 35 (on Rotor)
DAF-225Ex & DAF-225E: 31 (on Rotor)
DAF-180E & DAF-180D: 27 (on Rotor)
DAF-150D: 21 (on Rotor)
Target Material Diameter DAF-250Ex & DAF-225Ex: 24” (Optimal)
DAF-225E: 15” (Optimal)
DAF-180E: 10” (Optimal)
DAF-180D: 8” (Optimal)
DAF-150D: 6” (Optimal)
Dimensions
Weight DAF-250Ex: 5,400 lbs.
DAF-225Ex: 5,200 lbs.
DAF-225E: 4,700 lbs.
DAF-180E: 3,300 lbs.
DAF-180D: 3,200 lbs.
DAF-150D: 2,300 lbs.
Rotor Diameter DAF-250Ex, DAF-225Ex, DAF-225E & DAF-180E: 20”
DAF-180D & DAF-150D: 18”
Exterior Width DAF-250Ex: 103”
DAF-225Ex: 102”
DAF-225E: 100”
DAF-180E: 88”
DAF-180D: 87”
DAF-150D: 72”
Exterior Height DAF-250Ex: 61” (w/Pushbar); 38” (wo/Pushbar)
DAF-225Ex: 58” (w/Pushbar); 38” (wo/Pushbar)
DAF-225E: 55” (w/Pushbar); 38” (wo/Pushbar)
DAF-180E: 55” (w/Pushbar); 37” (wo/Pushbar)
DAF-180D: 58” (w/Pushbar); 44” (wo/Pushbar)
DAF-150D: 59” (w/Pushbar); 26” (wo/Pushbar)
Exterior Depth DAF-250Ex: 50” (w/Pushbar); 33” (wo/Pushbar)
DAF-225Ex: 51” (w/Pushbar); 33” (wo/Pushbar)
DAF-225E: 55” (w/Pushbar); 33” (wo/Pushbar)
DAF-180E: 45” (w/Pushbar); 27” (wo/Pushbar)
DAF-180D: 51” (w/Pushbar); 31” (wo/Pushbar)
DAF-150D: 48” (w/Pushbar); 29” (wo/Pushbar)
Hydraulic
Cylinders DAF-250Ex & DAF-225Ex: 115 (max)
DAF-225E & DAF-180E: 170 (max)
DAF-180D: 115 (max)
DAF-150D: 85 (max)
Torque DAF-250Ex, DAF-225Ex, DAF-180E & DAF-180D: 502 lbs.-ft. (max motor (T max at Vg max))
DAF-225E: 907 lbs.-ft. (max motor (T max at Vg max))
DAF-150D: 450 lbs.-ft. (max motor (T max at Vg max))
Operating Pressure DAF-250Ex, DAF-225Ex, DAF-225E & DAF-180E: 6000 PSI
DAF-180D & DAF-150D: 5000 PSI
Rotation Speed DAF-250Ex & DAF-225Ex: 2250 RPM
DAF-225E: 2350 RPM
DAF-180E: 2400 RPM
DAF-180D: 2550 RPM
DAF-150D: 2600 RPM
Variable Displacement Axial Piston Motor DAF-250Ex & DAF-225Ex: 2
DAF-225E, DAF-180E, DAF-180D & DAF-150D: 1
Nm DAF-250Ex, DAF-225Ex, DAF-180E & DAF-180D: 681
DAF-225E: 1230
DAF-150D: 610
Required Continuous Flow DAF-250Ex: 80 gal/min
DAF-225Ex: 75 gal/min
DAF-225E: 60 gal/min
DAF-180E: 50 gal/min
DAF-180D: 35 gal/min
DAF-150D: 23 gal/min
Pressure Line I.D. DAF-250Ex & DAF-225Ex: 1.25” (#20)
DAF-225E, DAF-180E & DAF-180D: 1” (#16)
DAF-150D: 075” (#12)
Return Line I.D. DAF-250Ex & DAF-225Ex: 1.25” (#20)
DAF-225E, DAF-180E & DAF-180D: 1” (#16)
DAF-150D: .75” (#12)
Drain Line DAF-250Ex & DAF-225Ex: 1” (#16)
DAF-225E: .75” (#12)
DAF-180E & DAF-180D: .675” (#10)
DAF-150D: .625” (#10)
Operational
Cutting Width DAF-250Ex: 99”
DAF-225Ex: 85”
DAF-225E: 88”
DAF-180E & DAF-180D: 74”
DAF-150D: 59”
Carrier Power DAF-250Ex: 250 HP
DAF-225Ex: 200 HP
DAF-225E: 175 HP
DAF-180E: 125 HP
DAF-180D: 85 HP
DAF-150D: 75 HP
Cutting Distance DAF-250Ex, DAF-225Ex & DAF-225E: .4” (from Ground Level)
DAF-180E, DAF-180D & DAF-150D: .8” (from Ground Level)
  • Standard: Sharpenable Bolt-on Forged Blades
  • Hydraulic Pushbar
  • Bolt-in Wear Liner for DAF-250Ex, DAF-225Ex, DAF-225E, DAF-180E, DAF180D
