• Heavy duty, 4-cycle, direct injection, turbocharged, charge air cooled diesel engine provides maximum reliability.
• Brushless alternator reduces service and maintenance requirements and meets temperature rise standards for Class H insulation systems.
  • Open delta excitation design provides virtually unlimited excitation for maximum motor starting capability.
  • Automatic voltage regulator (AVR) provides precise regulation.
• Electronic Governor Control — isochronous control, maintains frequency to within ±0.25% from no load to full load.
• Full load acceptance of standby nameplate rating in one step (NFPA 110, para 5-13.2.6).
• Sound attenuated, weather resistant, steel housing provides operation at 66 dB(A) at 23 feet. Fully lockable enclosure allows safe unattended operation.
• Internal fuel tank with direct reading of fuel gauge.
• E-coat and powder coat paint provides durability and weather protection.
• Fuel/water separator removes condensation from fuel for extended engine life. Panel mounted alarm light included.
• Complete engine analog instrumentation includes DC ammeter, oil pressure gauge, water temp. gauge, fuel level gauge, tachometer/hour meter, preheat indicator, and emergency shutdown monitors.
• ECU750 — automatic CANBUS engine control with LED status indicator lights.
• Automatic start/stop control — automatically starts the generator set during a commercial power failure when used in conjunction with a transfer switch.
• Complete generator analog instrumentation includes voltage regulator control, ammeter phase selector switch, voltmeter phase selector switch, AC voltmeter, AC ammeter, frequency meter, panel light, and circuit breaker.
• Automatic safety shutdown system monitors the water temperature, engine oil pressure, overspeed and overcrank.  Warning lights indicate abnormal conditions.
• Complete power panel. Fully covered; three-phase terminals and single phase receptacles allow fast and convenient hookup for most applications including temporary power boxes, tools and lighting equipment. The GFCI receptacles are NEMA 5-20, and the auxiliary outputs use CS6369 twistlock receptacles.
• Voltage selector switch offers the operator a wide range of voltages that are manually selectable. Fine tuning of the output voltage can be accomplished by adjusting the voltage regulator control knob to obtain the desired voltage.
• EPA emissions certified — Tier 4 final emissions compliant.
• Spill containment — Bunded design protects environment by capturing up to 119% of engine fluids.

• Tandem Axle Trailer with Electric or Hydraulic brake configurations
• Crankcase Vent Blanket w/Heating Element
• Battery Charger
• Water Heater
• Emergency Stop
• Low Coolant Level Shutdown
• Camlocks
• Audible Alarm
• Subbase Fuel Tanks (Custom size configurations)
