CHASSIS DESIGN

• Powered by a single Volvo engine that meets highest global standards including State IV (EU) and Tier-4 Final emissions requirements
• Standard rail guide system provides mobility and stability during digging.
• Available with highway speed undercarriages or on/off pavement wheeled models
• Automatic digging breaks provide convenience and time-saving productivity
• Short tail swing and low working profile makes work in tunnels and tight spaces possible
• Oscillation lock cylinders and strong box plate frame construction provide stable work platform that does not require outriggers
• Work at front, rear or side of chassis without the need for outriggers
• Variable displacement high torque piston motor powers two-speed power shift-on-the-fly transmission
• To enhance safe travel on rails, highway speed models have LED travel lights, forward and backward, and a change-of-direction alarm.

CHASSIS CAB

• Standard convenience features include an adjustable steering column, dual reading lights and radio
• Ergonomically designed interior with extra sound-deadening
• Rubber mounts isolate cab from frame, creating comfortable ride
• Easily visible gauges for oil pressure, coolant temperature, air tank pressures, fuel, DEF level, voltmeter and speed
• Engine shutdown controlled by engine electronics
• Indicator lights and controls for front axle engagement (4 x 4 models) and rear axle differential lock
• Comfort features including air suspension seat, sliding windows, fresh air heater and defroster and tinted glass

BOOM

• Full boom tilts 220° for efficient sloping, grading and spreading material
• No loss of power to attachment tilting capability
• Consistent boom force through the entire dig cycle
• Dig down at 75° angle
• Rugged boom telescopes out to 33’ 10”
• Low profile for work under bridges, trees and in tunnels
• Full-length boom visibility during the entire dig cycle
• Fast cycle times for ditching, loading and spreading
• Quick attach bolt system handles full range of attachments

OPERATOR CAB

• Choose the Gradall, Deere or SAE joystick pattern using an in-cab switch
• Quiet, roomy cab and comfortable seating module, with joystick controls built into the armrests
• Internal tooth swing bearing provides smooth, stable movement
• With foot pedals, reposition carrier at speeds up to 20 mph
• Excellent visibility of the boom through the entire dig cycle
• Standard air conditioning
• Optional rollover protection
• Removable, stowable front window brings fresh air into the cab
• All-weather cab
• Tinted safety glass windows
• Skylight
• Acoustical lining
• Four-way adjustable seat
• AM/FM radio
• Filtered fresh air heater
• Defroster
• Air conditioning
• Front window slides to overhead storage
• Mirrors on right and left sides
• Seat belt
• Windshield wiper and washer
• High/low beam headlights
• Parking lights
• LED brake lights
• Four-way hazard lights
• LED turn indicator lights
• LED work lights
• LED swing lights
• Axle oscillation lock switch
• FRA spec 360 degree strobe lighting
• Dual air horn
• Front facing air horn

ADVANCED SYSTEMS

• High performance, high reliability 24-volt electrical system
• Legendary Bosch Rexroth design and reliability
• All new, modern high-pressure hydraulic system is electronically controlled with pressure-compensated, load-sensing valves, providing additional fuel-saving advantages

EXCAVATOR

• Short tail swing won't obstruct traffic
• Stable digging platform for work in any direction, without need to stop and lower outriggers
• Triangular telescoping boom design, with full power through the entire dig cycle
• Cycle speeds comparable or exceeding conventional excavators
• Electronic joysticks provide precise control over boom and attachment positioning

UNDERCARRIAGE

• Full-time 4-wheel drive transfer case delivers power from the hydraulic drive motor to the drive axles
• Both axles equipped with internal wet-disc type service brakes
• Steering axle fitted with oscillation lock cylinders
• FRA Spec Travel Lighting and Alarms
• Offset Dual Tire and Rims
• Super single (optional)

UNDERCARRIAGE DRIVE

• Variable displacement high torque piston motor powers two-speed power shift transmission
• Speed mode selection can also be done while moving
• Electronically operated travel alarm signals excavator movement

RAIL GEAR

• Guide wheel rail gear system allows excavator to be propelled by the drive system of the machine
• DMF 1650 (50,000 lbs. each) Hi-Rail axle assemblies
• 16” guide wheels (custom profile available)
• High-strength alloy steel axles
• Wheel brakes work in conjunction with excavator braking system
• Hi-Rail gear controlled from operator cab
• Rail sweeps front and rear
• Tow bar plates front and rear
• Frame assemblies are pinned on for easy installation and removal.
• Front and rear axles have 3” slotted suspension
• Steering lock
• Rail gear cylinder guards

CONTROLS

• Two electronic joysticks (hoist and bucket, telescope and swing)
• One rocker switch (tilt) control
• Joysticks mounted on arm pods
• Quick change joystick pattern switch (Gradall, SAE, Deere)
• Self-centering joysticks and pedals; when controls are released, power for movement disengages and swing and tilt brake set automatically
• Tilting/telescoping steering column
• Hydraulic foot pedal controls braking functions
• Travel speed is regulated with an electronic foot pedal control
• Switch on the FWD/REV selector provides 1st/2nd gear selection
• Independent rocker switches control rail gear, axle oscillation, park brake and hazard lights
• Switch on column provides marker lights, high/low headlights and direction indicators
• AREMA decals
• Engine Controls and Instrumentation
  • Key ignition/starter switch; throttle and lockable main battery disconnect switch
  • Air cleaner condition indicator
  • Electronic monitor indicates fuel level, low battery charge, lube oil pressure, high coolant temperature, engine rpm and engine hours
  • Fuel saving auto idle feature sends engine rpm to idle when control circuits are in neutral for seven seconds

ATTACHMENTS

• Excavating Buckets
• Ditching Buckets
• Boom Extension
• Tree Limb Shear
• Fixed Thumb Grapple
• Sleeper Changer
• Sleeper Layer
• Ballast Tamper
• Ballast Bucket
• Ballast Broom
• Ballast Blade
• Flail Mower
• Kinshofer NOX Rotator

• Vandalism protection kit including window covers
• ROPS protective cab
