Grove TMS875-2

New Grove Truck-Mounted Crane for Sale

New Grove TMS875-2 Truck-Mounted Crane for Sale

Quick set-up is a feature of Grove TMs along with long reach, high capacity booms and highway speed travel capabilities. A front outrigger is standard for 360° operation. Grove truck cranes are popular choices because of their extensive list of standard features.

The TMS875-2 brings the latest truck crane technologies from Grove to the 75-ton size class. The new lightweight carrier design capably roads up to 28,000 lb of counterweight with no fall-off loads or wing weights and has capacities that are up to 26% stronger than its closest competitor.

  • 75 t (75 USt)
  • 12,2 m - 39,0 m (39.4 ft – 128.0 ft) five-section MEGAFORM™ boom
  • TWIN-LOCK™ boom pinning system
  • Manual or hydraulic 10,5 m - 17,6 m (34.5 ft - 57.6 ft) bi-fold swingaway extension options and an 8 m (26 ft) insert
  • Crane Control System (CCS)
  • High visibility cab with 20° tilt
  • Up to 12 700 kg (28,000 lb) counterweight with hydraulic removal system



  • MEGAFORMTM boom: The Grove MEGAFORM™ boom shape eliminates weight and increases capacity compared to conventional shapes. The simplified TWIN-LOCK™ boom pinning system automatically pins the sections in position using two horizontal large diameter pins. A single cylinder inside the boom reduces weight which has been used elsewhere to strengthen the machine.
  • Counterweight: Up to 12 700 kg (28,000 lb) of counterweight can be power installed and removed from the superstructure cab – allowing for easy transport to and from the job site.
  • Control system: Crane functions are controlled by Crane Control System (CCS). CCS offers a user-friendly interface, two full graphic displays mounted vertically for easier viewing and a jog dial for easier navigation and data input. The system allows the electronic controllers to be reprogrammed by the operator for specific speed and reaction. Parts commonality across Grove, Manitowoc and Potain product lines enhances operator familiarization and serviceability.
  • Outriggers: Two-stage outriggers provide four position settings - 0%, 54%, 77%, and 100%.
  • Optional power luffing extension: For improved up-and-over reach, a power luffing extension is available on the TMS875-2. It is hydraulically offsettable from the superstructure cab, 0° to 45°.
Body
Chassis Torsionally rigid frame, four-axle carrier, fabricated from high strength, low alloy steel with towing and tie-down lugs
Cab All aluminum construction cab with acoustical lining tilts hydraulically to +20° and includes tinted safety glass, air conditioning, adjustable operator’s seat with hydraulic suspension, hinged front (with wiper) and rear windows, sun visor and window shade. Other features include diesel heater/defroster, stereo radio/disc player, armrest integrated crane controls, and ergonomically arranged instrumentation
Single-driver design, aluminum fabricated with acoustical lining and tinted safety glass. Air conditioning. Fabric covered seat with air adjustment. Driving controls and engine instrumentation including tilt telescope multifunction steering wheel, tachometer, speedometer, trip meter, voltmeter, water temp., oil, fuel level, air pressure gauge, engine high temp./low oil pressure A/V warning.
Other standard items include display for back-up and passenger side cameras, hot water heater/defroster, electric windshield wash/wipe, fire extinguisher, wireless rigging remote with battery charging station, seat belt and door lock.
Dimensions
Length 47’
Width 23.91’
Height 11.8’
Weight 105,656 lbs.
Turning Radius 45.4’
Engine
Engine Make Cummins
Engine Model X 12
Engine Type Diesel engine, turbo-charged
Cylinders 6
Torque 1550 lb-ft at 1400 rpm
Fuel Tank Capacity 72 Gallons
Drivetrain
Axles Front: (2) tube-type steering axles, 2,12 m (83.4 in) track.
Rear: (2) single reduction drive axles, 1,89 m (74.5 in) track. Inter-axle differential locks. Drive: 8 x 4 x 4.
Transmission Roadranger 11 speeds forward, 3 reverse, manual.
Optional automated Eaton Fuller Ultrashift® PLUS Transmission.
Hydraulic
Hydraulic Capacity 147 Gallons
Hydraulic System Two load-sensing axial piston variable displacement pump (load sensing) with power limiting control and one gear pump for slewing and steering. Dual fan electric oil cooler. On screen display of hydraulic oil temperature.
Operational
Brakes S-cam, dual air split system operating on all wheels. Spring-applied, air released parking brake acting on rear axles. Air dryer. ABS with traction control.
Suspension Front: Walking beam with air bags and shock absorbers.
Rear: Walking beam with air bags and shock absorbers.
Tires Front: 445/65R 22.5 tubeless, mounted on aluminum disc wheels.
Rear: 315/80R 22.5 tubeless, mounted on aluminum disc wheels.
Steering Front axles, single circuit, mechanical steering with hydraulic power assist.
Counterweight 13,000 lbs. consisting of multiple sections with hydraulic installation/removal system operated from the cab.
Gradeability 70%, 1st gear
Swing Two planetary gearboxes with axial piston fixed displacement motors. Infinitely variable to 1.9 rpm. Spring-applied park brakes and hydraulic service brakes.
Outrigger Controls Located in the superstructure cab and on either side of carrier. Crane level indicators located at all stations.
Auto leveling and wireless remote control standard.
Rope Diameter 3/4”
Rope Length Main hoist: 653’
Aux. hoist: 420’
Line Speed 423 fpm
Boom
Boom 39.4 ft – 128.0 ft four-section MEGAFORM™ boom with TWIN-LOCK™ pinning system
Max Boom Length 40’-128’
Max Tip Height-Boom 137’
Hoist Main and auxiliary hoists are powered by axial piston motors with planetary gears and brakes. “Thumb-thumper” hoist drum rotation indicator alerts operator of hoist movement. Standard minimum wrap indication with lock-out.
Boom Elevation Single lift cylinder with integrated valve provides boom angle from -3.0˚ to 80.0˚.
Max Capacity 75 USt
Boom Nose Four nylatron sheaves, mounted with removable pin-type rope guards.
Quick reeve boom nose. Removable auxiliary boom nose with removable pin type rope guard.
Hoist Line Pull Line pull: 1st layer-22,100 lbs.; 3rd layer-18,900 lbs.; 5th layer-16,500 lbs.
Electrical
Electrical System Four maintenance-free batteries provide 24 V electrical system.
Standard lockable battery disconnect.
Lighting Lighting package including turn indicators, head, tail, brake, and hazard warning lights.
  • BOOM
    • 40-128 ft (12,2 m – 39,0 m) four-section, MEGAFORM, Twin-Lock boom
    • Max tip height: 137.0 ft (41,8 m)
    • Optional 34.5 ft- 57.6 ft (10,5 m - 17,6 m) telescoping swingaway lattice extension (manual or hydraulic)
    • Max tip height with jib: 194.3 ft (59,2 m)
  • CARRIER
    • Engine: Cummins X12 6-cylinder turbocharged and after-cooled, 475 bhp
    • Eaton manual or automated transmission
  • SUPERSTRUCTURE
    • Chassis-mounted outrigger controls with auto-leveling feature
    • Manitowoc CCS crane control system with two full graphic displays and jog dial
    • MAXBase asymmetrical outrigger position system
  • COUNTERWEIGHT
    • Standard and heavy lift counterweight packages both interchangeable with TMS9000E and TMS9000-2
    • Counterweights hydraulically controlled from cab or rigging remote
  • DIMENSIONS
    • Overall length: 46.9 ft (14,3 m)
    • Overall width: 8.3 ft (2,5 m)
  • Aluminum fenders with rear storage compartments
  • Dual rear viewmirrors
  • Electronic back-up alarm
  • Sling/tool box
  • Tire inflation kit
  • Air cleaner restriction indicator
  • Headache ball stowage tray
  • Air conditioning
  • Air horn
  • Hoist access platform
  • Auxiliary Lighting and Convenience Package Includes amber strobe light for superstructure and carrier cab, and boom nose mounted, boom position indicator light (fully wired)
  • Dual boom base mounted floodlights (manual or power-adjusted)
  • Hook blocks
  • Pintle hook (rear)
  • Trailing Boom Package
  • Aluminum outrigger pads
  • Outrigger mat stowage and mats
  • Counterweight packages
  • Tow cable
  • Wind speed indicator
  • Winterfront radiator cover
  • Counterweight slings
  • Cross axle differential locks
  • Electric controlled 360° lock
  • Rear counterweight stowage
  • Single axis joysticks
  • Boom dolly camera
