Hamm HD 14i TT

New Hamm Tandem Roller for Sale

New Hamm HD 14i TT Compactor for Sale

The articulated compact rollers in the HD CompactLine, with operating weights of between 1.4 and 4.5 t, are real all-rounders for asphalt construction, earthwork and landscape gardening. Their operation is extremely easy and requires no special language skills. Moreover, the wasp-waist rollers impress on account of their optimum visibility and outstanding driving and handling characteristics attributable primarily to the three-point articulated swivel joint.

  • Simple, intuitive and language-neutral control

  • Simple transport, simple loading

  • Ergonomic driver platform

  • Excellent view of tires, machine and construction site

  • Compact dimensions
Dimensions
Length 116.7”
Width 51”
Height 107.1” (w/cab)
102” (w/ROPS)
71.7” (Loading)
Weight 8,478 lbs.
Wheelbase 76.8”
Ground Clearance 12”
Turning Radius 102.4”
Steering Angle 8°
Width over Tires Rear: 50.2”
Front: 44.4”
Tire Size Rear: 80-16
Front: 10.5
Engine
Engine Model V2403-CR
Cylinders 4
Horsepower 50.9 HP
Fuel Tank Capacity 19.3 gpm
Emission Standards EU Stage V/EPA Tier 4
Wheel Load Rear per tire: 1,028 lbs.
Front per tire: 1,235 lbs.
Drivetrain
Tires Rear: 4
Front: 3
Steering Articulate Steer
Speeds 0,0-6,2 (infinitely variable)
Climbing ability 40%
Operational
Drum Width 44.4”
Working Width 50.2”
Water Tank Capacity 68.7 gpm
Sprinkler System Pressure
Weights
Axle Load Rear: 4,112 lbs.
Front: 3,704 lbs.
Weight on Tires 9,702 lbs. (Max)
7,817 lbs. (w/ROPS)
7,067 lbs. (no cab wo/ROPS)
8,478 lbs. (w/cab)
  • Description: Tandem roller with two sets of tires
  • Exhaust emissions Category: EU Stage V/EPA Tier 4
  • Total Length: 116.7”
  • Width: 51.”
  • Total Height: 102”
  • Width over tires: Front-44.4” & Rear-50.2”
  • Height, loading, min: 71.7”
  • 12 V outlet
  • Lighting package as per road traffic regulations
  • CompactLine front suspension eyelet
  • Vibration-isolated operator’s platform
  • Hydrostatic steering
  • Operator’s platform with entry from both sides
  • Pressure water sprinkling with interval switch
  • Battery isolation switch
  • Handrails
  • Dashboard cover, lockable and weather-resistant
  • Dashboard with displays, indicator lights and switches
  • 3-point articulation
  • ROPS cabin with heating
  • Tool kit
  • Tow hitch
  • Water drain valve
  • Water tank cover, lockable
  • Bonnet with sound insulation
  • Rotating beacon
  • Working light
  • Back-up alarm
  • Automatic engine-off function
  • Thermal aprons
  • Plastic tarpaulin on ROPS
  • Radio
  • Safety belt monitoring device
  • Driver's seat with seat heating, black synthetic leather, comfort equipment

*Price, if shown, is Manufacturer's Suggested Retail Price (MSRP) and does not include government fees, taxes, dealer freight/preparation, dealer document preparation charges or any finance charges (if applicable). MSRP and/or final actual sales price will vary depending on options or accessories selected.

New Equipment Sales only available in assigned territories where Kirby-Smith Machinery, Inc. is a licensed distributor. Not all manufacturer's brands available at each location. Please contact your local Kirby-Smith branch if you have questions regarding availability.

View Brochure

Main Technical Specifications
MAKE Hamm
MODEL HD 14i TT
