• 3-YEAR WARRANTY on HP 200 – HP 1800 models
• ABF TECHNOLOGY
• Automatic Variance on Speed and Power
• Fuel Saving
• Dual Shock Absorber Systems
• Field-Replaceable Lower Insert Bushing
• Low Operating Pressure
• Simple and Efficient Design
• Custom Bracket Caps
• Power Greasing System
• Quiet Operation
• Single In-body Accumulator
• Strongest Warranty Protection in the Business

• All lndeco hammers have a special intelligent hydraulic system, enabling them to automatically vary the energy and frequency of the blows according to the hardness of the material being demolished. This optimises the hydraulic pressure delivered by the machine, thus improving productivity and enhancing the overall performance.
• Exclusive features make it possible to completely do away with seals in the distribution area, a decisive factor in extending the working life of the hammer and significantly reducing downtimes.  Such as:
  • The synchronised internal distributor aligned with the piston
  • The oil cushions for vibration dampening
  • The short hydraulic flow pattern
• The use of special low-alloy steels, exclusively manufactured according to lndeco's own formula greatly lengthen the average working life of the major hammer components.
• The housing is made out of extra-strength HARDOX® steel wear plates, which eliminate buckling.
• The piston is divided into two parts, for greater impact energy and lower operating costs.
• The centralised greasing system enables the sliding parts to remain lubricated even when the hammer is operating horizontally, thus considerably reducing wear and tear on components and extending product lifetime.
• The "quick change" interchangeable bushing is available in various materials for different jobs; it is inserted into the lower tool bushing where the tool moves, and reduces maintenance times and costs, by cutting out the long machine downtimes needed to replace the traditional fixed bushing.
• All carriers which mount lndeco hammers benefit from the lndeco dual shock-absorption system: an internal hydraulic one and a mechanical one, located outside the body, which substantially reduce the vibrations transmitted to the excavator.
• The excavator boom is also subject to lower stress levels, as lndeco hammers are considerably lighter under working conditions than rival makes in the same class. Alongside the standard versions there is also a super-soundproofed Whisper version, whose body is lined internally with sound absorbent material and an "anti-rumble" paint, which – combined with a few modifications to the bushing – enable noise emission levels to be considerably reduced.
• By lowering pressure peaks, the rechargeable hydraulic/nitrogen accumulator also reduces stress in the excavator hydraulic circuit, keeps the gas charge and energy per blow constant, and reduces maintenance and operating costs.
• he ABF (Anti Blank Firing) system, installed as standard on all of the medium- and large-range lndeco hammers, cuts out blank fire by eliminating any down pressure from the hammer whenever the tool is not resting firmly on the surface to be demolished.  This increases the service life of all components subject to wear and tear, as well as reducing stress to the hammer body and excavator arm.
• As well as being efficient and reliable, lndeco hydraulic hammers are now proving to be even more environmentally-friendly even more efficient hydraulic system, the HP series has now also become FS (Fuel Saving). Compared to other manufacturers' models of equivalent weight and performance, lndeco hammers require less oil per minute and lower operating pressure. And as using lower hydraulic power means reducing the number of revolutions per minute on the carrier, they lead to fuel savings of up to 20%, while ensuring optimum performance and maximum productivity. This becomes even more evident when comparing the lndeco hammer with gas or gas/oil powered products of similar size manufactured by competitors.

ACCESSORIES

• IDA (lndeco Dust Abatement) System: An innovative system that is particularly effective for reducing wear and tear on components, extending the working life of the hammer and protecting operators against exposure to microparticles of crystalline silica. It consists of a jet of high-pressure water spray, emitted by a number of nozzles 11 I on the casing, which prevents dust from harming both the tool and the operator.  Recently updated to comply with the latest OSHA directives, the system is available in two different versions:
• High-pressure system: Available for medium-large to large hammers, it is made up of an air compressor and a high-pressure water pump, mounted onto the excavator and driven by two hydraulic motors powered by the excavator. A set of electrohydraulic valves enable the excavator operator to activate the pump and compressor independently, thus starting up either one or both of the protection devices: the dust-abatement kit, which uses a fine water spray and the dust shield, which uses the internal pressurization of the hammer to prevent dust, water and debris from getting into the hammer through the bushing, as can occur during tunnel demolitions and underwater excavations.
• Low-pressure system: Designed for smaller hammers and pulverizers, the technology involves inserting a vaporizing plate with four nozzles, where the mounting bracket is attached, which enables it to cover the whole working area (whatever position it is in) and reduce the amount of dust produced, even on windy days. The new system only needs a lowpressure water supply and the sprayers turn on automatically only when the attachment is in action, thus also reducing water consumption.
• Anti-Grease and Anti-Dust System: This system, which is crucial when working in dusty environments and when tunnelling, is made up of two collars. Both are adherent to the tool, and which prevent dust from getting in and grease from getting out, improving lubrication levels and thus lengthening the working life of the main hammer components.
• lndeco Lube automatic greasing systems: Among the most important accessories on hydraulic hammers, automatic greasing systems developed exclusively for lndeco by Bekalube technical staff are designed to keep hammers in perfect working order, by using just the right amount of lubricant and cutting out the down times needed for the operator to carry out manual greasing. There are two types of greasing unit - either an on-board system that can be fitted directly onto the hammer and which uses a cartridge pump, or else an excavator-mounted unit with its own grease tank.  In both cases, these systems are connected to the hammer through a single centralized greasing point, which enables the lubricant to reach all of the bushings and the moving parts at the tool, inside the hammers and on the retaining axle.
• On-Board greasing systems:
  • Single-shot cartridge pump works with only one hydraulic line, accepts the standard LubeMaxx cartridge, and is recommended for hammers HP 800 - HP 2000
  • LubeMaxx Continuous-Flow greaser is recommended for hammers HP 3000 - HP 10000
  • LubeMaxx XL Continuous-Flow greaser accepts two standard LubeMaxx cartridges and is recommended for hammers HP 12000 to HP 25000
• Carrier-mounted systems:
  • 1.6 gal hydraulically or electrically-operated tank
  • 5.8/6.6 gal drum immersion pump and hydraulic or electric action
• Special lndeco Supreme lubricant: It is vital that a specific lubricant be used to ensure the durability of the main components of the hammer. lndeco's Supreme lubricant, with solid additives is particularly resistant to oxidation, can withstand extreme pressures and temperatures and shows excellent adhesion and water resistance
• Pins and bushings: Designed to make it easier to mount all lndeco products onto the excavator boom, with or without a mounting bracket.
• Mounting brackets: Each lndeco mounting bracket model can be used with all lndeco products in the same class.
• Folding mounting bracket: A special mounting bracket for folding the hammer away directly under the carrier boom.
• Connecting hoses: We recommend using original lndeco high- and low-pressure hoses to connect various tools to the hydraulic system on the carrier.

Application Areas

• Mining and Quarry
  • Preliminary Works
    • Overburden removal
    • Bench, road & ramp leveling
    • Roof, face & rib scaling
  • Secondary Demolition
    • Boulder reduction in rock pile
    • Removing blockages at crushing systems
  • Primary Rock Breaking
    • Selective rock breaking
    • Blastfree mining
• Demolition & Renovation
  • Light Demolition
    • Demolition of masonry structures
    • Autoclaved aerated concrete
  • Demolition of Non-Reinforced Concrete Structures
    • Primary demolition of lightweight and standard concrete
    • Primary demolition of heavyweight concrete
    • Wall Elements
    • Secondary demolition
  • Composite Steel & Concrete Structure Demolition
    • Primary demolition of lightweight and standard reinforced concrete
    • Primary demolition of heavyweight steel – reinforced concrete
    • Secondary Demolition floors, slabs and beams
    • Fiber-reinforced concrete
  • Pavement Demolition
    • Asphalt
    • Concrete
    • Composite surfaces
• Earth Moving and Construction
  • Earth Moving Works
    • Trenching
    • Ground excavation
  • Foundation Works
    • Building foundation excavation
    • Ground leveling
• Infrastructures
  • Tunnelling
    • Tunnel excavation
    • Roof, face & rib scaling
  • Underwater Application
    • Dredging
    • Dock deepening & extension
    • Canal deepening & extension
  • Trenching
    • Oil & gas, water & sewage (deep trenching)
• Metallurgical Industry
  • Slag Recycling
    • Boulder reduction in slag heaps
    • Removing blockages at crushing systems
  • Cleaning & Debricking
    • Ladles
    • Converter mouths
    • Kilns
• Agriculture and Forestry
  • Gardening & Landscaping
    • Fencing
    • Ground excavation
    • Rock breaking
    • Pit planting
    • Stump splitting
