Morbark 223 Stand-Alone Flail

New Morbark Stand-Alone Flail for Sale

New Morbark 223 Stand-Alone Flail for Sale

The 223 Flail is designed to work in conjunction with chippers like the Morbark 23 Chiparvestor®, the 40/36 Whole Tree Drum Chipper or similar machines. The Morbark Integrated Control System allows for fine adjustment of feed rate and flail drum speed so that bark removal is maximized and removal of “good” fiber is minimized for superior end products.

  • ADJUSTABLE FEED RATE AND FLAIL DRUM SPEED: Morbark Integrated Control System allows for fine adjustment of speed so that bark removal is maximized and removal of “good” fiber is minimized.
  • LARGE ENGINE/HYDRAULIC INSPECTION AREA: Large dedicated work/inspection area gives easy access to engine and hydraulic components.
  • DRIVES: Kawasaki direct drive flail motors allow for adjustments of up to 700 RPM.
  • SEGMENTED FLAIL DRUM: Segmented flail drum provides better wear life than traditional tubular style drums.
  • Large dedicated work/inspection area gives easy access to engine and hydraulic components.
  • Segmented flail drum provides better wear life than traditional tubular style drums.

Stand-Alone Flail

With a large 56” x 23” (142.24 cm x 58.42 cm) infeed opening, the 223 accepts logs up to 23” (58.42 cm) in diameter at a feed rate from 70-150 feet per minute.

  • Kawasaki direct drive flail motors allow for adjustments of up to 700 RPM.

Track Stand-Alone Flail

With a large 56" x 23" (142.24 cm x 58.42 cm) infeed opening, the 223 accepts logs up to 23" (58.42 cm) in diameter at a feed rate from 40-145 feet per minute (12.9-44.2 m/min).

  • Kawasaki direct drive flail motors allow for adjustments of up to 578 RPM.



Models

  • Stand-Alone Flail
  • Track Stand-Alone Flail
Axle
Axle Weight Stand-Alone: 45,000 lbs. suspension (Tandem Axle)
Dimensions
Length Stand-Alone: 25’2”
Track Stand-Alone: 24’1.5”
Width Stand-Alone: 9’10”
Track Stand-Alone: 9’9.75”
Height Stand-Alone: 13’4”
Track Stand-Alone: 10’7.5”
Weight Stand-Alone: 46,700 lbs.
Track Stand-Alone: 54,100 lbs.
Transport Length Stand-Alone: 33’5”
Transport Height Stand-Alone: 9’11”
Engine
Engine Make Cat (Engine & Dual-Axle Trailer)
Horsepower 375 HP
Hydraulic Capacity 200 Gallons
Fuel Capacity 230 Gallons
Drivetrain
Tracks Stand-Alone: Optional 320L Caterpillar
Track Stand-Alone: CAT 320L 500mm Triple Grousers
Drive Flail: Hydraulic
Operational
Drum Speed Adjustable from 0 to 700 RPM (Flail)
Infeed Opening 56” x 23”
Feed Rate Adjustable from 70 to 150 ft/min
  • One top hydraulically driven feed roller mounted on a yoke assembly
  • Two stationary bottom hydraulically driven feed rollers
  • Dual horizontal chain flail drums (one stationary bottom, one carried by a floating yoke) with segmented drums; each equipped with eight flail chain rods
  • Remote control
  • Hydraulic flail drive
  • Light package
  • 11-HP (8.2 kW) air compressor



Stand-Alone Flail

  • Discharge system consisting of 62" (157.48 cm) x 19" (48.26 cm) opening and 61.5" (156.21 cm) x 11.5" (29.21 cm) hydraulically powered ram
  • Flail Drum Speed: Adjustable from 0 to 550 RPM
  • Feed Rate: Adjustable from 70 ft/min (21.34 m/min) to 150 ft/min (45.72 m/min)

Track Stand-Alone Flail

  • Discharge system consisting of 62" (157.48 cm) x 22" (55.88 cm) opening and 61.5" (156.21 cm) x 11.5" (29.21 cm) hydraulically powered ram
  • Flail Drum Speed: Adjustable from 0 to 578 RPM
  • Feed Rate: Adjustable from 40 ft/min (12.9 m/min) to 145 ft/min (44.2 m/min)
  • ESPAR heating system for cold-weather start
