The 6400XT Wood Hog Horizontal Grinder Next Generation doesn't just grind wood; it grinds away inefficiencies. Experience a significant boost in productivity, as the machine processes large volumes of material in record time. Time saved is money earned.The 6400XT is Morbark's largest grinder and is designed for operations that need the most durable, highest output machine. Equipped with the latest grinding technology, the 6400XT ensures precision and consistency in every grind. From variable speed controls to intelligent monitoring systems, this machine sets the standard for modern wood processing.

• Morbark Integrated Control Systems (MICS): Automatically adjusts feed rates and monitors pressures and feed wheel position to maximize production and engine efficiency.
• Extended Maintenance Platform: The area between the hood and the engine has been reconfigured to provide an additional 31.5″ (80 cm) of working space for better access for maintenance and changing screens.
• Auto Belt Tensioning System: Automatic hammermill drive-belt tension system allows ease of setting adjustments based on grinding application.
• Tracks: NT38 Strickland Undercarriage with (500 mm) triple grouser pads
• PT Tech Hydraulic Torque Limiter: Available on the 6400XT Next Gen, driveline protection has never been better. Utilizing PT Tech technology and with virtually zero maintenance, the PT Tech Torque limiter electronically reacts and hydraulically separates the driveline from the hammermill to protect your investment.
• Hammermill: Pin & plate hammermill system with (18) replaceable hammers, (18) replaceable rakers, and (18) Alpha 3 inserts
• Electric Power: Electric power is available as an option for a cleaner and often more cost-effective way to process organic waste (available on trailer unit).
• Externally Adjustable Break-Away Torque Limiter: Flexible, easily adjustable torque limiter helps protect the driveline and hammermill for damage.

Models

• 6400X Wood Hog
• 6400XT Wood Hog
• 6400XT Wood Hog Next Generation
• 6400XT Wood Hog Next Generation with Transport Dolly System

6400X Wood Hog

Ideal for high-volume producers processing wood waste, land clearing and storm debris into saleable products, the 6400X Wood Hog weighs in at 87,360 lb (39,675 kg) and measures 9'10" (2.99 m) wide, allowing the unit to be transported to nearly all domestic and international markets. The infeed bed is 24 inches (60.96 cm) longer than previous Morbark grinders in the 1,000-plus horsepower range and has sloped infeed flares. This configuration improves operator sight lines for more efficient loading of material.

FEATURES AND BENEFITS

• The area between the hood and the engine has been reconfigured to 31.5" (80 cm) of working space, for better access to components for general maintenance or to change screens.
• The Morbark Integrated Control Systems (MICS) automatically adjusts feed rates and monitors pressures and feed wheel position to maximize production and engine efficiency.
• Standard on the 6400X is a removable infeed chain return floor, which allows excess material to fall away to minimize the wear on the floor, bed chain and inserts, particularly useful in land-clearing or other applications with dirty material.
• The hydraulic hinged and locking door allows quick and easy access for changing grates.
• The patent-pending PT Tech hydraulic torque limiter allows for the ultimate driveline protection while allowing ease of setting adjustments based on the grinding application. The Torque Limiter will release and disconnect from the main driveline when the set torque is exceeded and will initiate a series of protocols to prevent further damage while notifying the operator that the system has been tripped

6400XT Wood Hog

Ideal for processing wood waste, land clearing and storm debris into marketable end-products, the 6400XT Wood Hog weighs in at less than 96,500 lb (43,772 kg) and measures 11'10" (3.6 m) wide with the standard Caterpillar 325L undercarriage with 600 mm double grousers, allowing the unit to be transported to nearly all domestic and international markets. The infeed bed is 24 inches (60.96 cm) longer than previous Morbark grinders in the 1,000-plus horsepower range and has sloped sides. This configuration improves operator sight lines for more efficient loading of material.

FEATURES AND BENEFITS

• Extended area between the hood and the engine provides additional working space for better access to components for general maintenance or to change screens.
• The Morbark Integrated Control Systems (MICS) automatically adjusts feed rates and monitors pressures and feed wheel position to maximize production and engine efficiency.
• Independent hammermill drive belt tensioner
• Hydraulically operated hood to allow quick and easy access for changing grates
• A proven drive line protection system protects against catastrophic damage from contaminants

6400XT Wood Hog Next Generation

The 6400XT Wood Hog Horizontal Grinder Next Generation doesn't just grind wood; it grinds away inefficiencies. Experience a significant boost in productivity, as the machine processes large volumes of material in record time. Time saved is money earned. The 6400XT is Morbark's largest grinder and is designed for operations that need the most durable, highest output machine. Equipped with the latest grinding technology, the 6400XT ensures precision and consistency in every grind. From variable speed controls to intelligent monitoring systems, this machine sets the standard for modern wood processing.

6400XT Wood Hog Next Generation Features and Benefits

• Enhanced Frame Design
• Automatic Hammermill Drive Belt Tensioning System
• PT Tech Hydraulic Torque Limiter
• VTection® Vibration Detection System
• Hydraulic Rod Puller
• ESPAR Heating System
• Spare Grate Rack
• Magnetic End Pulley

6400XT Wood Hog Next Generation with Transport Dolly System Features and Benefits

• Transport Dolly System
• Enhanced Frame Design
• Automatic Hammermill Drive Belt Tensioning System
• PT Tech Hydraulic Torque Limiter
• VTection® Vibration Detection System
• Hydraulic Rod Puller
• ESPAR Heating System
• Spare Grate Rack
• Magnetic End Pulley
