• Exhaust emissions category: EU Stage 5/US EPA Tier 4f
• Operating and travel speed: 0-288.7 ft/min (0-3.3 mph)
• Working width max: 7’8”
• Working depth: 13.8”
• Operating weight: 106,924 lbs.
• Displacement: 7.2 Imp.gal
• Maximum power: 1,038 HP

Basic Machine

• Basic machine with engine
• The machine can be used as a cold recycler in rear-loading mode or as a cold milling machine in front-loading mode
• Soundproof lining of engine compartment
• Diesel engine power controller for optimum milling and mixing results
• Load limit controller for optimum operation in down-cut mode
• Engine cooling system with temperature-controlled fan speed
• Machine frame providing optimum visibility for rear- and front-loading operations
• Battery-operated hydraulic unit
• Mechanical drum drive via high-performance V-belts with automatic belt tensioner
• Milling drum gearbox for down-cut operation in rear-loading mode (replaceable w/optional equipment)

Milling and Mixing Unit

• Milling drum housing FB2350

Milling and Mixing Rotor

• Three electrically selectable milling drum speeds
• Quick and easy conversion from rear-loading to front-loading operation
• Water spray system with automatic on/off function including two spray bars in the milling and mixing unit
• Hydraulically movable and adjustable front drum plate with exchangeable carbide elements
• Rear drum sealing plate with hydraulic conveyor lifting feature and exchangeable carbide elements
• Hydraulically lifting side plates, optimized for both directions of operation
• Milling and mixing rotor FB2350 HT22 LA15 with 198 picks

Loading of the milled and mixed material

• Discharge conveyor, 1,100 mm wide, with hydraulic folding device (replaceable w/optional equipment)
• Conveyor system with manually or automatically adjustable conveying speed
• Water spray system in the primary conveyor

Injection system/Addition of binders

• Single ESL (FB2350): injection system with VARIO injection bar for water or bitumen emulsion (800 l/min) (replaceable w/optional equipment)

Paving Unit

• Model without spreading auger and without paving screed (replaceable w/optional equipment)

Machine control and levelling system

• Multifunctional colour control screen displaying important machine operating conditions
• Comprehensive machine diagnostics on the machine’s control screen
• Automated features relieving the operator of a part of his workload
• Four exterior control panels for operating functions performed by the ground crew
• LEVEL PRO levelling system for milling depth control, including one control screen and one each electrical height sensor in the hydraulic cylinders on the side plates, right and left

Operator’s platform

• Fully anti-vibration mounted operator’s platform
• Convenient access to the operator’s platform, right and left
• Fold-out extension of operator’s platform, right
• Large storage compartment and stand-up seats, right and left
• Two mirrors at the front, two mirrors at the rear of the machine
• Walk-through operator’s platform with one each control panel, right and left
• The control panels can be adjusted in height, rotated and positioned in line with ergonomic principles and the machine’s direction of operation
• Lockable control panel covers

Chassis and height adjustment

• PTS-automatic alignment of the machine parallel to the pavement surface
• ISC-intelligent track speed control including hydraulic four-track drive
• Fourfold full-floating axle for high machine stability
• High ground clearance for improved access when replacing picks or removing the milling and mixing unit
• Four-track steering system offering the following steering modes in both directions of operation: crab, cornering or straight-ahead mode
• Extremely wear-resistant, two-part EPS Plus polyurethane track pads

Miscellaneous

• Air compressor system, max. 8 bar
• Camera at the front with two screens, right and left
• Washdown system with hose reel and cleaning gun
• Comprehensive LED lighting system, 24 V
• “Welcome” and “Go home” lights feature including LED lighting in the area of the operator’s platform and access
• Comprehensive toolkit in lockable toolbox
• EMERGENCY STOP switches in appropriate positions on the machine
• Pre-fitting for installing the WITOS FleetView control unit “WIRTGEN Road Technologies Telematics and on-site Solutions” (WITOS) is the intelligent telematics system of the WIRTGEN Road Technologies for efficient fleet and service management worldwide
• Water tank filling from rear of machine (replaceable w/optional equipment)
• Standard painting in RAL 9001 (cream) (replaceable w/optional equipment)
• WITOS FleetView-professional telematics solution to optimize machine use and servicing (replaceable w/optional equipment)

Basic Machine

• Milling drum gearbox for up-cut operation in rear-loading mode

Loading of the milled and mixed material

• Model without discharge conveyor
• VCS extraction system
• Hydraulically adjustable deflector plate on the discharge conveyor
• Supports for discharge conveyor

Injection system/Addition of binders

• Duel ESL (FB2350): injection system with VARIO injection bars for water and bitumen emulsion (800 l/min + 800 l/min)
• Dual ESL foamed bitumen (FB2350): injection system with VARIO injection bars for water and foamed bitumen (800 l/min, 500 kg/min)
• Model without injection system

Paving Unit

• Paving screed model AB 375 T and spreading auger
• Automatic extending screed control, right and left, using Sonic Ski sensors
• Cross slope sensor for extending screed

Machine control and levelling system

• Ultrasonic sensor for wire or ground scanning
• Additional LEVEL PRO control screen
• Pre-fitting for multiplex system comprising 4 sensors sockets
• 3-fold multiplex, right, including 2 ultrasonic sensors
• 3-fold multiplex, right and left, including 4 ultrasonic sensors
• Cross slope sensor for machine

Operator’s platform

• Canopy with electro-hydraulic fold-down feature

Miscellaneous

• Hydraulically operated filling pump for water refilling
• Painting in one special colour (RAL)
• Painting in two special colours (RAL)
• Painting in max. two special colours with the lower part of the machine painted in special colour (RAL)
• Model without WITOS FleetView
• Support arm for accommodating the push bar and hoses during tanker truck changes
• High-pressure water cleaner, 190 bar, 151 l/min
• Guide plates on the front track units to guide previously deposited material
• Milling drum rotation device for milling and mixing units FB2350
• Pneumatic hammer with pick driver and ejector drift
• Hydraulic pick ejector drift
• Diesel tank filling pump with 5.00-m suction hose
• Additional camera on the discharge conveyor
• Additional monitor system including five cameras and monitor
• Pre-fitting for two LED lighting balloons
• LED lighting balloon, 24 V
• Suction hose for hot bitumen 3”, 4000 LG
• Suction hose for water or emulsion 3”, 5000 LG
