Takeuchi TL8R2

New Takeuchi TL8R2 Track Loader for Sale

The TL8R2 is the latest addition to Takeuchi’s fully redesigned track loader lineup setting yet another standard for performance, durability, serviceability, and operator comfort.  The 74.3 hp TL8R2 features a radial lift loader design offering greater bucket breakout and lift arm forces. The TL8R2’s new undercarriage design features repositioned travel motors with internally routed drive lines, double and triple flange track rollers, as well as a quiet ride track design that greatly improves ride quality. This track loader come standard with many new features including a completely upgraded operator’s station with a redesigned overhead door, 5.7” color multi-informational display with rearview camera, LED lighting package, and high-torque spin turn. In addition to these standard features, optional features available on the TL8R2 include creep mode, load sensing auto shift, and high flow auxiliary hydraulics. With all these new features, the TL8R2 is sure to prove itself as one of Takeuchi’s most versatile and capable track loaders to date.
Dimensions
Length 9' 1.8"
Height 7' 3.8" (2,230 mm)
Ground Clearance 11.4" (290 mm)
Length w/ Bucket 11' 5.2"
Length w/o Bucket 9' 1.8"
Dump Height 7' 11.3" (2,420 mm)
Height to Bucket Pin 10' 1.2" (3,080 mm)
Dump Reach 2' 4.3"
Rollback @ Ground 28°
Dump Angle 38°
Angle Departure 30°
Reach @ Max Height 2' 4.3" (720 mm)
Width wo/Bucket 5’ 5.4” (1,660 mm)
Clearance Radius 7' 2.3" (2,190 mm)
Engine
Engine Make Kubota
Engine Model V3307-CR-TE5B
Engine Type Tier 4 Final
Horsepower 74.3 hp
Displacement 203.2 cu in
Torque 192.0 ft-lb
Fuel Consumption 2.8 gal/hr
Fuel Tank Capacity 28.3 gal
Rated RPM 2,600 rpm
Drivetrain
Track Width 15.7" (400 mm)
Track Length 4‘ 7.9" (1,420 mm)
Ground Pressure 4.5 psi (31 kPa)
Hydraulic
Hydraulic Capacity 15.9 gal
Hydraulic Flow 19.1 gpm Primary Circuit 33.8 gpm High Flow (optional)
Hydraulic Pressure 3,045 psi
Operational
Weight 8,807 lb - 9,182 lb
Tipping Load 6,041 lb
Bucket Breakout Force 6,204 lb
Breakout Force 5,957 lb
Traction Force 9,733 lb
ROC 2,116 lb
Operating Load 3,020 lb (50 % of Tipping Load)

ENGINE

  • EU Stage V / EPA Tier 4 Emission Compliant
  • Turbocharged
  • High Pressure Common Rail Fuel Injection System
  • DOC+DPF Exhaust After Treatment
  • Automatic Fuel Priming System
  • Active Power Control, Power Management System
  • Working Modes
  • Standard and ECO Mode
  • Double Element Air Cleaner
  • Hand and Foot Throttle Control
  • High Capacity Radiator and Hydraulic Oil Cooler Mounted Side-by-Side on Swing Out Frame

ELECTRICAL

  • 5.7” Multi-Informational Color Display with Rear View Camera
  • Sealed Rocker Switches
  • 12 Volt System with 60 amp Alternator
  • LED Work Lights: Two Front and Two Rear
  • Heavy Duty, Easy Access Battery
  • Engine Preheat System
  • Hour Meter
  • Back-up Alarm
  • Horn
  • Takeuchi Fleet Management - Telematics System*


UNDERCARRIAGE AND FRAME

  • Double Reduction Planetary Drives
  • Permanently Sealed Track Rollers with Metal Face Seals
  • Fully Welded Frame with Integrated Cross Members
  • Two-Speed Travel
  • 400 mm Quiet Track Design with Flotation Tread
  • Grease Type Track Adjuster
  • Front and Rear Tie-Down Points
  • Rear Bumper Integrated into Frame


OPERATOR’S STATION

  • Tilt-up Operator’s Station
  • Deluxe High Back Suspension Seat
  • Rear Pivoting Lap Bar with Arm Rest
  • ROPS / FOPS Level I Structure
  • Retractable 2” Seat Belt
  • Pressurized Cab with Roll-up Door, A/C, Heat, Defrost and Front Wiper, and AM / FM / MP3 Radio (Cab Only)
  • 3 Point Retractable Seat Belt (optional)
  • Polycarbonate Front Door (Optional Cab)*
  • FOPS Level II Roof Guard Kit (optional) - Rear Wiper (Cab Standard Equipment in Europe Only)


HYDRAULIC & WORKING EQUIPMENT

  • Radial Lift Design
  • Hydraulic Pilot Controls
  • Arm Float
  • Cushioned Arm Cylinders
  • Hydraulic Self Leveling System
  • Proportional Auxiliary Hydraulic Controls with Detent
  • Pressure Relieving Flat Faced Coupler Body
  • High Capacity Steel Hydraulic Tank
  • Mechanical Quick Hitch
  • Manual Parking Brake (optional)
  • Hydraulic Quick Hitch (optional)
  • High Flow Auxiliary Hydraulics 128.0 L/min (optional)



TAKEUCHI FLEET MANAGEMENT

  • Minimize Downtime
  • Remote Diagnostics
  • Utilization Tracking
  • Proactive Maintenance
  • Control Costs



*Price, if shown, is Manufacturer's Suggested Retail Price (MSRP) and does not include government fees, taxes, dealer freight/preparation, dealer document preparation charges or any finance charges (if applicable). MSRP and/or final actual sales price will vary depending on options or accessories selected.

New Equipment Sales only available in assigned territories where Kirby-Smith Machinery, Inc. is a licensed distributor. Not all manufacturer's brands available at each location. Please contact your local Kirby-Smith branch if you have questions regarding availability.

View Brochure

Main Technical Specifications
MAKE Takeuchi
